The main SMT production line consists of automated high-precision
state-of-the-art equipments from
anasonIC,Sumsung, Japan total 6 lines (Smallest SMT components size
can reach to 0201,capable of
0.6mm*0.3mm ~ 50mm*50mmQFP, 0.15mm gap, ±0.05 accuracy ).EMS
capacity can reach 150,000,000
components per month. Our engineering team has extensive experience
in DFM/DFA/DFT technologies.
SMT, BGA Rework, Re-balling, X-Ray are all readily achieveable.
Stencils can be cut and delivered inside
of 4 hours.
Al base thickness(mm) | 1.0,1.5,2.0 | 1.0,1.5,2.0 | E-Wintek |
Dielectric thickness(μm) | 60±5 | 60±5 | E-Wintek |
Copper thickness(μm) | 34±3 | 34±3 | E-Wintek |
Size(mm) | 340*520 | 340*520 | E-Wintek |
470*600 | 470*600 |
520*1200 | 520*1200 |
Peel strength(kgf/cm) | ≧1.8 | ≧1.8 | IPC-TM-650 2.4.9 |
Solder dip test(300℃ 30sec) | Pass | Pass | IPC-TM-650 2.4.13 |
Chemical ersistance | Pass | Pass | IPC-TM-650 2.3.2 |
Flammability(UL) | V-O | V-O | UL94 |
Surface resistance(ohm) | >E+14 | >E+14 | ASTM-D257 |
Volume resistance(ohm"cm) | >E+15 | >E+15 | ASTM-D257 |
Breakdown voltage(ACV/mil) | 900 | 900 | IPC-TM6502.5.6 |
Glass transition temp.(℃) | 120 | 120 | DSC |
Thermal conductivity(W/m.k) | 1.8 | 1.8 | ASTM-D5470 |
Shelf life(month) | 6 | 6 | E-Wintek |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
