Touch Screen Board LCD Display PCBA CTP Module Controller Board For
5 Inch
Product introduction:
1-40 Layers circuit board pcb pcba SMT assembly
· PCB Design Tools : Cadence Allegro,Mentor Graphics PADS,Altium
Designer,Protel SE,CR5000,Mentor WG,CAM350 etc.
· PCB Design And Layout Service : Specialize In High-speed PCB
Design, SI/PI/EMC Analysis.
· PCB Assembly Service : Quick Turn SMT Factory , Providing SMT
Assembly And Parts Sourcing Services.
· 2-64 layered PCBs, including HDI, Rigid, Rigid-flex & Flex
boards.
· Double-Sided PCB,Multilayer PCB,1-4-steps HDI PCB,Anylayer HDI
pcb,FPC PCB,Rigid-Flex PCB
Model Number: | ZYX-21737UYV | Place of Origin: | Shenzhen, China |
Number of Layers: | 10-Layer | Brand Name: | BQZYX+ |
Base Material: | FR2/FR4/FR5/CEM1 | Copper Thickness: | 0.5-5.0oz |
Board Thickness: | 1.6mm | Min. Hole Size: | 0.20mm |
Min. Line Width: | 0.15mm | Min. Line Spacing: | 0.15mm |
Surface Finishing: | HASL/ Lead Fres/Immersion | Specification: | IPC-A-610D |
ZYX is a professional PCB / PCBA manufacturer in Shenzhen China.Our
provide high quality bare PCB and PCB assembly service,including
components sourcing, function test,conformal coating and complete
assembly for clients all over the world.
ZYX provides superior service for automotive electronics, medical
electronics, telecommunications, industrial control, smart home and
other industries around the world.
Num. | Material Technology | Our Production | General Production |
1 | Regular/Special | 1.Our (TG170)FR4: high quality materials, excellent heat resistance, won't distort
break in high temperature, no foaming, no burning, good performance
in electrical charge, impact resistance, humidity-resistance
2.Our FR4 good performance in electrical charge, impact resistance,
humidity-resistance
3.Our CEM no-burr
4.Our Rogers Good performance in high frequency
5.Our Aluminum Excellent heat dispersion | 1.General FR4 High heat work
2.General CEM Expand and deform in damp conditions |
2 | Factory | We have automatic production line. The automatic production line
improves the precision and efficiency of PCB producing,it makes
surface brighter, cleaner and more smooth, and it helps reduce the
cost. | Artificial production line |
3 | Blind/buried via board, High Density Interconnect(1+1,N+1) | Application of HDI technology reducing the thickness and the volume
of PCB boards, increasing the density of 3-D wiring design. | Difficult manufacturer, high cost |
4 | Impedance | Good performance in reliability and stability of signal sending and
receiving | High cost |
5 | Surface Technics | 1.IMG:smooth surface, good adhesion, no oxidation under long using 2.gold plating(thick gold:1-50U"):good wear-resistance 3.HASL:better price, not easy oxidation, easy to welding, smooth
surface 4.HAL: better price, not easy oxidation, easy to welding | 1.IMG:high price 2.Gold plating(thick gold):high price 3.HAL:surface is not flat, not suitable for BAG packaging |
6 | Copper Via/Surface(20-25UM,0.5-60Z) | Laser holing: Min 0.1MM, Mechanical holing: Min 0.2MM | Hard to reach 0.1MM |
7 | Multilayer board(4-20 L),BGA(CPU) | BGA:high density, high performance, multifunctional, increase
thermal reliability, good performance in electroheat property, MIN
width/space: 3/3MIL
Multilayer board:strong microporous, high reliability | Difficult manufacturer,high cost |
8 | Test | To assure quality, avoid wasting after installing and scraping,
save cost, save the time of rework | Careless |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
