Multi Layered SMT Pcb Fabrication And Assembly RoHS FCC Certificate
Portable Type Coffee Machine With Cup And Controller Pcb Board Pcba
Product introduction:
PCB Fabrication and PCB Assembly is our core servicesZYX,From
multi-layered to flexible printed circuit boards, ZYX is your
one-stop shop. We provide our customers with PCB solutions and
services worldwide. especially more than 80% printed circuit board
are exported to oversea market. We have full of confidence to meet
your quality level.
As a 10 years PCB manufacturer in China, ZYX is providing the
latest printed circuit board technologies and highest quality
standards for electronics industry. You can trust us to meet your
demands, from small volume to mass production whatever the simplest
PCB boards or the most complex.
| Model Number: | ZYX-21720QE | Place of Origin: | Shenzhen, China |
| Supplier Type: | EMS factory | Brand Name: | BQZYX+ |
| Base Material: | FR2/FR4/FR5/CEM1 | Copper Thickness: | 0.5-5.0oz |
| Board Thickness: | 0.8-2.0mm | Min. Hole Size: | 0.20mm |
| Min. Line Width: | 0.15mm | Min. Line Spacing: | 0.15mm |
| Surface Finishing: | HASL/ Lead Fres/Immersion | Solder mask color: | green/black/white/red/blue/yellow |
ZYX is a professional PCB / PCBA manufacturer in Shenzhen China.Our
provide high quality bare PCB and PCB assembly service,including
components sourcing, function test,conformal coating and complete
assembly for clients all over the world.
ZYX provides superior service for automotive electronics, medical
electronics, telecommunications, industrial control, smart home and
other industries around the world.
Advantage Of PCB Assembly Service
• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC,
OQC
• 100% AOI inspection, including X-ray, 3D microscope and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking
test
OEM/ODM/EMS Services For PCBA:
· PCBA, PCB Board assembly: SMT & PTH & BGA
· PCBA and enclosure design
· Components sourcing and purchasing
· Quick prototyping
· Plastic injection molding
· Metal sheet stamping
· Final assembly
· Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
· Custom clearance for material importing and product exporting
PCB/PCBA Capacity:
| 1 | Material | FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder
Sheet, Halogen Free FR4, Ceramic Filling Material, Teflon, PI
Material, BT Material, PPO, PPE etc. |
| 2 | Board thickness | Mass production: 394mil(10mm) Samples: 17.5mm |
| 3 | Surface finish | HASL, Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion
Silver, ENEPIG, Gold Finger |
| 4 | PCB Max panel size | 1150mm × 560mm |
| 5 | Layer | Mass production: 2~58 layers / Pilot run: 64 layers, Flexible PCB:
1-12 Layers |
| 6 | Min hole size | Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
| 7 | PCBA QC | X-ray, AOI Test, Functional Test |
| 8 | Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity,
Hybrid, Partial hybrid, Partial high density, Back drilling, and
Resistance control. |
| 9 | Our service | PCB, Turnkey PCBA, PCB Clone, Housing, PCB Assembly, Component
sourcing, PCB manufacturing from 1 to 64 layers |
| 10 | Sanforized | Buried via, Blind via, Mixed Pressure, Embedded Resistance,
Embedded Capacitance, Local Mixed Pressure, Local High Density,
Back drill, impedance control. |
| 11 | SMT Capacity | 930Million Points/Day |
| 12 | DIP Capacity | 0.6Million Points/Day |
| 13 | Certificate | RoHS/FCC |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
