Rechargeable Balance Bms Pcb Prototype Assembly Service 3.2v
Lifepo4 Smt Pcba
Rechargeable Balance Bms3.2v Lifepo4 4s 10a 12.8v Circuit Board
PCBA
Product introduction:
ZYX is highly process focused, all PCB assemblies are verified for
part-placement accuracy; the use of critical checks such as signal
integrity, functionality and performance to test specifications are
fully incorporated into our PCBA testing procedures. Comprehensive
PCBA testing capabilities include functional PCBA testing equipment
and in-circuit testing (ICT).
| Model Number: | ZYX-21743NH | Place of Origin: | Shenzhen, China |
| Base Material: | FR-4 | Brand Name: | BQZYX+ |
| Board Thickness: | 1.6mm | Copper Thickness: | 1oz~4oz |
| Min. Hole Size: | 0.25mm | Min. Line Width: | 0.1mm/4mi |
| Min. Line Spacing: | 0.003" | Surface Finishing: | HASL Lead Free |
| Type: | lifepo4 battery BMS | Usage: | Lithium Battery Packs,LiFePO4 etc |
ZYX is an OEM manufacturer that focus on PCB/PCBA manufacturing
over 11 years. We have the capability to manufacture pcb ranging
from basic single sided boards up to 22 layer multilayers ,and
provide one stop turnkey services, including pcb layout,
manufacture, assembly, components source, function testing services
and so on.We established in 2010 and always provide high quality,
technically advanced products within the customer's timescales so
that we can provide the best electronic services for you.This
commitment, combined with the wealth of experience and expertise we
have built up over the years, means we can offer a total solution
to our customers PCB requirements - from front end engineering
through to in time deliveries.
Layer count | 1-28L,HDI |
| FR-4, High TG FR4, aluminium, FPC |
Teflon,PTFE (F4B,F4BK), Rogers (4003,4350,5880) |
Max board dimensions | 800mm*620mm |
Board shape | Rectangular,round,slots,cutouts,complex,irregular |
Board type | Rigid,flexible,rigid-flexible |
Board cutting | Shear,V-score,tab-routed,counter sunk |
Board thickness | 0.2~8.0mm, Flex 0.1~0.25mm |
Thickness Tolerance | ±10% |
Min line width / space | 3mil/3mil |
Minimum Drilling Hole (Mechanical) | 0.1mm |
Minimum laser hole | 0.075mm |
Blind Hole/buried plate | YES |
Hole Position/hole Tolerance | PTH:±0.076MM |
NPTH:±0.05mm |
InnerLayer Copper Thickness | 0.5-3 oz |
OutLayer Copper Thickness | 0.5-4 oz |
Impedance control tolerance | ±10% |
Surface finish | HASL,Lead free HASL,ENIG,Immersion Tin,Immersion Silver,OSP... |
Solder mask | Double-sided green,red,white,blue,black,etc |
Silkscreen | Double-sided or single-sided in white,black,or negative |
PCB Testing | E-test, Flying probe test |
Acceptable File Format | Gerber RS-274X,274D,AutoCAD'S DXF,DWG,Pro-E,Ki-CAD |
| |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
