18um 35um Double Side PCB Board Multilayer Pcb Design And
Fabrication
About us:
Was founded in year of 2010 .With being OEM manufacturer
specializing in PCB/PCBA Sensors etc with 11-year,nowadays,we have
built up our strong product research and development center and we
are devoting ourselves to electronics smart
product. combined with the wealth of experience and expertise we
have built up over the years, means we can offer a total solution
to our customers one stop Service
requirements – from front end engineering through to in time
deliveries.
Our PCBA Capability
SMT, PTH, mixed technology
SMT: 2,000,000 solder joints per day
DIP: 300,000 joints per day
Ultra fine pitch, QFP, BGA, μBGA, CBGA
Advanced SMT assembly
Automated insertion of PTH (axial, radial, dip)
Cleanable, aqueous and lead-free processing
RF manufacturing expertise
Peripheral process capabilities
Pressfit back planes & mid planes
Device programming
Automated conformal coating
For E-Test
Universal Tester
Flying Probe Open/Short Tester
High power Microscope
Solder ability Testing Kit
Peel Strength tester
High Volt Open & Short tester
Cross Section Molding Kit With Polisher
Model Number: | ZYX-2181VGTFJ | Place of Origin: | Shenzhen, China |
Base Material: | FR4 | Brand Name: | BQZYX+ |
Copper Thickness: | 18 um, 35 um | Board Size: | Custom made |
Min. Hole Size: | 3 mil | Silkscreen color: | White |
Surface Finishing: | Lead Free HASL | PCB Standard: | IPC-A-610 D |
ZYX is a professional OEM manufacturer for PCB design, PCB
production, component souring and SMT assembly, we sincerely would
like to be your reliable OEM supplier from China.
With more than 11 years experience in the PCB industry, our
services
Includes:
- PCB/PCBA Contract Manufacturing
- Reverse Engineering Services
- PCB Design and Assembly
- Component Procurement / Material Management
- Product Design
- Fast PCB/ PCBA Prototyping
- Cable and Wire Assemblies
- Plastics and Molds
- AOI,X-Ray Testing, other Function Testing Service
PCB Capability:
Article | Description | Capability |
Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
Board Thickness | Standard | (0.1-4mm±10%) |
Min. | Single/Double:0.008±0.004” |
4layer:0.01±0.008” |
8layer:0.01±0.008” |
Bow and twist | no more than 7/1000 |
Copper Weight | Outer Cu weight | 0.5-4 0z |
Inner Cu weight | 0.5-3 0z |
Drilling | Min size | 0.0078”(0.2mm) |
Drill deviation | ±0.002″(0.05mm) |
PTH hole tolerance | ±0.002″(0.005mm) |
NPTH hole tolerance | ±0.002″(0.005mm) |
Solder Mask | Color | Green,white,black,red,blue… |
Min solder mask clearanace | 0.003″(0.07mm) |
Thickness | (0.012*0.017mm) |
Silkscreen | Color | white,black,yellow,blue… |
Min size | 0.006″(0.15mm) |
Max Size of Finish Board | 700*460mm |
Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
PCB Outline | Square,circle,irregular(with jigs) |
Package | QFN,BGA,SSOP,PLCC,LGA |
FAQ
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
