Factory Home Electronics Double Layer PCB And PCBA With Competitive
Price
ZYX strives to be your one stop solution partner in EMS supply
chain, including PCB design , PCB fabrication and PCBassembly
(PCBA).We provide some of the most advanced PCB technology,
including HDI PCBs,multilayer PCBs, Rigid-Flexible
PCBs.Wecan support from quick turn prototype to medium / mass
Production.
In general, our global customers are very impressed with our
services:rapid response, competitive price and quality
commitment.Providing more valuable technical service and overall
solution is the way ZYX forward.
Looking to the future, O-leading will concentrate on the innovation
and development of electronics manufacturing technology as always,
and make persistent efforts on PCB / PCBA one-stop service to
provide first-class services and create
more value for ourcustomers.
Model Number: | ZYX-2181PXDRY | Place of Origin: | Shenzhen, China |
Type of services: | Manufacturer | Brand Name: | BQZYX+ |
Testing: | 100% E-testing | Certificate: | ROSH.ISO9001.ISO4001. |
MOQ: | 1pcs | PCB Test: | Flying probe and AOI (Default)/Fixture Test |
Certification: | ce, RoHS, BIS(ISI) | PCB Assembly Test: | Visual Inspection (default), AOI, FCT, X-RAY |
Specifications
1. We offer One-shop PCAB/PCB manufacturing service
2.11 year of turnkey ODM/OEM experience
3. We can provide F4B,F4BK, Teconic,Arlon,Rogers materia PCB
4. Timely customizations PCBs and PCBAs
2. Detailed Terms for Pcb Assembly
Technical requirement:
(1) Professional Surface-mounting and Through-hole soldering
Technolog
(2) Various sizes like 1206,0805,0603 components SMT technology
(3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
(4) PCB Assembly With UL,CE,FCC,Rohs Approval
(5) Nitrogen gas reflow soldering technology for SMT.
(6) High Standard SMT&Solder Assembly Line
(7) High density interconnected board placement technology capacity
Research and development sales of network communication products. R
& D and sales of consumer electronics products ems department
customers provide full service led products R & D, smt and testing
Article | Description | Capability |
Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
Board Thickness | Standard | (0.1-4mm±10%) |
Min. | Single/Double:0.008±0.004” |
4layer:0.01±0.008” |
8layer:0.01±0.008” |
Bow and twist | no more than 7/1000 |
Copper Weight | Outer Cu weight | 0.5-4 0z |
Inner Cu weight | 0.5-3 0z |
Drilling | Min size | 0.0078”(0.2mm) |
Drill deviation | ±0.002″(0.05mm) |
PTH hole tolerance | ±0.002″(0.005mm) |
NPTH hole tolerance | ±0.002″(0.005mm) |
Solder Mask | Color | Green,white,black,red,blue… |
Min solder mask clearanace | 0.003″(0.07mm) |
Thickness | (0.012*0.017mm) |
Silkscreen | Color | white,black,yellow,blue… |
Min size | 0.006″(0.15mm) |
Max Size of Finish Board | 700*460mm |
Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
PCB Outline | Square,circle,irregular(with jigs) |
Package | QFN,BGA,SSOP,PLCC,LGA |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
